Edit product details -
Fiber Optic Multiswitch (8 if + 1 Rf)
Preview
Save
Save and Continue Edit
Copy product
Delete
ID
Created on
12/13/2023 10:32:12 AM
Updated on
12/20/2023 2:13:34 PM
URL of the product page
https://alderishop.com/fiber-optic-multiswitch-8-if-1-rf-2/
Product type
Simple product
Grouped product
Bundled product
Published
Visibility
Fully visible
In search results
On product detail pages
Not visible
Product template
Default Product Template
Standard
English
العربية
Turkce
Russian (Russia)
السلوفاكية (سلوفاكيا)
Product name
Short description
Full description
<ul><li>Optical multiswitch system over a single fiber optic core</li><li>Optical receiver and multiswitch in one box only</li><li>Gain adjustment for each input</li><li>Voltage LED indicators</li><li>High Insulation compact plug and play</li><li>High performance and special power supply</li><li>External TERR Input</li><li><li>Input 1 SC/APC (Full Band) Optical Connector</li><li>Subscriber Outputs 10 F Connectors (75 ohm)</li><li>Cascade Outputs 9 F Connectors (8IF+1RF) (75 ohm)</li><li>Satellite Frequency Range 950-2150 Mhz</li><li>Frequency Range 47-870MHz</li><li>Gain Setting 0...20dB</li><li>Optical Wavelength 1270...1410nm (CWDM)</li><li>Max. Optical Input Power 2 mW</li><li>Satellite-to-Satellite Isolation > 35dB</li><li>Satellite-Terr Isolation > 40dB</li><li>Isolation between Subscriber Outputs > 36dB</li><li>Supply Power 12V-5V 3000mA / 18W</li><li>Operating Temperature -25 ... + 50Cº</li><li>Dimensions 270x235x58mm</li><li>Weight 770gr.</li></li></ul>
Optical multiswitch system over a single fiber optic core
Optical receiver and multiswitch in one box only
Gain adjustment for each input
Voltage LED indicators
High Insulation compact plug and play
High performance and special power supply
External TERR Input
Input 1 SC/APC (Full Band) Optical Connector
Subscriber Outputs 10 F Connectors (75 ohm)
Cascade Outputs 9 F Connectors (8IF+1RF) (75 ohm)
Satellite Frequency Range 950-2150 Mhz
Frequency Range 47-870MHz
Gain Setting 0...20dB
Optical Wavelength 1270...1410nm (CWDM)
Max. Optical Input Power 2 mW
Satellite-to-Satellite Isolation > 35dB
Satellite-Terr Isolation > 40dB
Isolation between Subscriber Outputs > 36dB
Supply Power 12V-5V 3000mA / 18W
Operating Temperature -25 ... + 50Cº
Dimensions 270x235x58mm
Weight 770gr.
Product name
Short description
Full description
<ul><li>Optical multiswitch system over a single fiber optic core</li><li>Optical receiver and multiswitch in one box only</li><li>Gain adjustment for each input</li><li>Voltage LED indicators</li><li>High Insulation compact plug and play</li><li>High performance and special power supply</li><li>External TERR Input</li><li><li>Input 1 SC/APC (Full Band) Optical Connector</li><li>Subscriber Outputs 10 F Connectors (75 ohm)</li><li>Cascade Outputs 9 F Connectors (8IF+1RF) (75 ohm)</li><li>Satellite Frequency Range 950-2150 Mhz</li><li>Frequency Range 47-870MHz</li><li>Gain Setting 0...20dB</li><li>Optical Wavelength 1270...1410nm (CWDM)</li><li>Max. Optical Input Power 2 mW</li><li>Satellite-to-Satellite Isolation > 35dB</li><li>Satellite-Terr Isolation > 40dB</li><li>Isolation between Subscriber Outputs > 36dB</li><li>Supply Power 12V-5V 3000mA / 18W</li><li>Operating Temperature -25 ... + 50Cº</li><li>Dimensions 270x235x58mm</li><li>Weight 770gr.</li></li></ul>
Optical multiswitch system over a single fiber optic core
Optical receiver and multiswitch in one box only
Gain adjustment for each input
Voltage LED indicators
High Insulation compact plug and play
High performance and special power supply
External TERR Input
Input 1 SC/APC (Full Band) Optical Connector
Subscriber Outputs 10 F Connectors (75 ohm)
Cascade Outputs 9 F Connectors (8IF+1RF) (75 ohm)
Satellite Frequency Range 950-2150 Mhz
Frequency Range 47-870MHz
Gain Setting 0...20dB
Optical Wavelength 1270...1410nm (CWDM)
Max. Optical Input Power 2 mW
Satellite-to-Satellite Isolation > 35dB
Satellite-Terr Isolation > 40dB
Isolation between Subscriber Outputs > 36dB
Supply Power 12V-5V 3000mA / 18W
Operating Temperature -25 ... + 50Cº
Dimensions 270x235x58mm
Weight 770gr.
Product name
Short description
Full description
<ul><li>نظام بصري متعدد المحولات على قلب واحد من الألياف الضوئية</li><li>جهاز الاستقبال البصري والمحول المتعدد في صندوق واحد فقط</li><li>كسب التعديل لكل المدخلات</li><li>مؤشرات LED الجهد</li><li>التوصيل والتشغيل المدمج عالي العزل</li><li>الأداء العالي وإمدادات الطاقة الخاصة</li><li>مدخلات TERR الخارجية</li><li><li>الإدخال 1 موصل بصري SC/APC (نطاق كامل).</li><li>مخرجات المشترك 10 موصلات F (75 أوم)</li><li>مخرجات متتالية 9 موصلات F (8IF+1RF) (75 أوم)</li><li>نطاق تردد الأقمار الصناعية 950-2150 ميجا هرتز</li><li>نطاق التردد 47-870 ميجا هرتز</li><li>إعداد الكسب 0...20 ديسيبل</li><li>الطول الموجي البصري 1270...1410 نانومتر (CWDM)</li><li>الأعلى. طاقة الإدخال الضوئية 2 ميجاوات</li><li>عزل الأقمار الصناعية إلى الأقمار الصناعية> 35 ديسيبل</li><li>عزل القمر الصناعي > 40 ديسيبل</li><li>العزل بين مخرجات المشترك > 36 ديسيبل</li><li>طاقة إمداد 12 فولت - 5 فولت 3000 مللي أمبير / 18 وات</li><li>درجة حرارة التشغيل -25 ... + 50 درجة مئوية</li><li>الأبعاد 270 × 235 × 58 ملم</li><li>الوزن 770 جرام.</li></li></ul>
نظام بصري متعدد المحولات على قلب واحد من الألياف الضوئية
جهاز الاستقبال البصري والمحول المتعدد في صندوق واحد فقط
كسب التعديل لكل المدخلات
مؤشرات LED الجهد
التوصيل والتشغيل المدمج عالي العزل
الأداء العالي وإمدادات الطاقة الخاصة
مدخلات TERR الخارجية
الإدخال 1 موصل بصري SC/APC (نطاق كامل).
مخرجات المشترك 10 موصلات F (75 أوم)
مخرجات متتالية 9 موصلات F (8IF+1RF) (75 أوم)
نطاق تردد الأقمار الصناعية 950-2150 ميجا هرتز
نطاق التردد 47-870 ميجا هرتز
إعداد الكسب 0...20 ديسيبل
الطول الموجي البصري 1270...1410 نانومتر (CWDM)
الأعلى. طاقة الإدخال الضوئية 2 ميجاوات
عزل الأقمار الصناعية إلى الأقمار الصناعية> 35 ديسيبل
عزل القمر الصناعي > 40 ديسيبل
العزل بين مخرجات المشترك > 36 ديسيبل
طاقة إمداد 12 فولت - 5 فولت 3000 مللي أمبير / 18 وات
درجة حرارة التشغيل -25 ... + 50 درجة مئوية
الأبعاد 270 × 235 × 58 ملم
الوزن 770 جرام.
Product name
Short description
Full description
<ul><li>Tek fiber optik core üzerinden optik multiswitch sistemi</li><li>Optik alıcı ve multiswitch sadece Tek kutuda</li><li>Her giriş için kazanç ayarı</li><li>Voltaj Led göstergeleri</li><li>Yüksek İzolasyon kompakt tak ve çalıştır</li><li>Yüksek performans ve özel güç kaynağı</li><li>Harici TERR Girişi</li><li><li>Giriş<span style="white-space:pre"> </span>1 SC/APC (Full Band) Optik Konnektör</li><li>Abone Çıkışları<span style="white-space:pre"> </span>10 F Connectors (75 ohm)</li><li>Kaskat Çıkışları<span style="white-space:pre"> </span>9 F Connectors (8IF+1RF) (75 ohm)</li><li>Uydu Frekans Aralığı<span style="white-space:pre"> </span>950-2150 Mhz</li><li>Frekans Aralığı<span style="white-space:pre"> </span>47-870 MHz</li><li>Kazanım Ayarı<span style="white-space:pre"> </span>0...20dB</li><li>Optik Dalga Boyu<span style="white-space:pre"> </span>1270...1410nm (CWDM)</li><li>Max. Optik Giriş Gücü<span style="white-space:pre"> </span>2 mW</li><li>Uydu-Uydu İzolasyon<span style="white-space:pre"> </span>> 35dB</li><li>Uydu-Terr İzolasyon <span style="white-space:pre"> </span>> 40dB</li><li>Abone Çıkışları arası İzolasyon<span style="white-space:pre"> </span>> 36dB</li><li>Besleme Gücü<span style="white-space:pre"> </span>12V-5V 3000mA / 18W</li><li>Çalışma Sıcaklığı <span style="white-space:pre"> </span>-25 ... + 50Cº</li><li>Ölçüler<span style="white-space:pre"> </span>270x235x58mm</li><li>Ağırlık <span style="white-space:pre"> </span>770gr.</li></li></ul>
Tek fiber optik core üzerinden optik multiswitch sistemi
Optik alıcı ve multiswitch sadece Tek kutuda
Her giriş için kazanç ayarı
Voltaj Led göstergeleri
Yüksek İzolasyon kompakt tak ve çalıştır
Yüksek performans ve özel güç kaynağı
Harici TERR Girişi
Giriş
1 SC/APC (Full Band) Optik Konnektör
Abone Çıkışları
10 F Connectors (75 ohm)
Kaskat Çıkışları
9 F Connectors (8IF+1RF) (75 ohm)
Uydu Frekans Aralığı
950-2150 Mhz
Frekans Aralığı
47-870 MHz
Kazanım Ayarı
0...20dB
Optik Dalga Boyu
1270...1410nm (CWDM)
Max. Optik Giriş Gücü
2 mW
Uydu-Uydu İzolasyon
> 35dB
Uydu-Terr İzolasyon
> 40dB
Abone Çıkışları arası İzolasyon
> 36dB
Besleme Gücü
12V-5V 3000mA / 18W
Çalışma Sıcaklığı
-25 ... + 50Cº
Ölçüler
270x235x58mm
Ağırlık
770gr.
