Technical Specifications
Exterior - Interior: painted galvanized sheet - painted galvanized sheet and its alternatives
Sheet thickness: 0.40 - 0.80 mm
Minimum - Maximum length: 2.5m - 15m
Density: 40-42 kg-m3 polyurethane 42-45 kg-m3 pyre
Thermal conductivity coefficient: 0.27 - 0.11 W-m2 K (according to TS EN 14509)
Flammability class: PUR Insulated: B-s2;d0
Infrared insulated: B-s1;d0

Top Metal (mm)	Lower Metal (mm)	Panel Thickness (mm)	Panel Weight (kg)	Heat Resistance	Thermal Permeability Coefficient
				R (m2 K/W)	D (W/m2 K)
0,50	0,50	80	12,16	3,7	0,27
0,50	0,50	100	13,1	4,65	0,21
0,50	0,50	120	14,05	5,54	0,18
0,50	0,50	150	15,45	07,01	0,14
0,50	0,50	200	17,8	9,19	0,11
