Edit product details - Voltage, Frequency and Ground Sensor

Copy product

Created on

3/28/2024 1:23:31 PM

Updated on

4/1/2024 1:12:39 PM

URL of the product page

https://alderishop.com/voltage-frequency-and-ground-sensor-2/

Product type

Published

Visibility

Product name

Short description

Full description

<ul><li>Phase measurement range 120-300V AC / 1V sensitivity</li><li>Frequency measurement range 10-500 Hz / 0.1 Hz precision</li><li>Soil measurement range 0-20V AC / 1V sensitivity</li><li>Maximum cable distance 50m</li></ul><p><google-sheets-html-origin style=""></google-sheets-html-origin></p><table xmlns="http://www.w3.org/1999/xhtml" cellspacing="0" cellpadding="0" dir="ltr" border="1" data-sheets-root="1" style="table-layout: fixed; width: 0px; border-collapse: collapse; border: none;"><colgroup><col width="176"><col width="389"></colgroup><tbody><tr style="height: 21px;"><td rowspan="1" colspan="2" data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Electrical:&quot;}" style="border: 1px solid rgb(0, 0, 0); overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Electrical:</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Operating voltage range&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Operating voltage range</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;4.5-5.5V DC&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">4.5-5.5V DC</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;operating current&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">operating current</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;<2.6mA (5V DC)&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">&lt;2.6mA (5V DC)</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Phase measurement range&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Phase measurement range</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;120-300V AC&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">120-300V AC</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Phase measurement accuracy&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Phase measurement accuracy</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;1V&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">1V</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Frequency measuring range&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Frequency measuring range</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;100-500 Hz&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">100-500 Hz</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Frequency measurement precision&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Frequency measurement precision</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;0.1Hz&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">0.1Hz</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Soil measurement range&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Soil measurement range</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;0-20V AC&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">0-20V AC</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Soil measurement accuracy&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Soil measurement accuracy</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;1V&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">1V</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="2" data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Communication:&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Communication:</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Protocol&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Protocol</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;MODBUS with RS485 address&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">MODBUS with RS485 address</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;cable distance&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">cable distance</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Maximum 50m&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Maximum 50m</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Cable type&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Cable type</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;0.8mm diameter cable (AWG20)&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">0.8mm diameter cable (AWG20)</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="2" data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;General:&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">General:</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Body&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Body</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;ABS Plastic&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">ABS Plastic</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;body type&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">body type</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Standard&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Standard</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Colour&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Colour</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Black&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Black</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Operating temperature&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Operating temperature</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;0ºC / +45ºC&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">0ºC / +45ºC</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Operating humidity&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Operating humidity</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;20-85%RH&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">20-85%RH</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Dimensions (HxWxD)&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Dimensions (HxWxD)</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;75x105x62mm&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">75x105x62mm</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Weight&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Weight</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;420g&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">420g</td></tr></tbody></table>

Phase measurement range 120-300V AC / 1V sensitivity
Frequency measurement range 10-500 Hz / 0.1 Hz precision
Soil measurement range 0-20V AC / 1V sensitivity
Maximum cable distance 50m

Electrical:
Operating voltage range	4.5-5.5V DC
operating current	<2.6mA (5V DC)
Phase measurement range	120-300V AC
Phase measurement accuracy	1V
Frequency measuring range	100-500 Hz
Frequency measurement precision	0.1Hz
Soil measurement range	0-20V AC
Soil measurement accuracy	1V
Communication:
Protocol	MODBUS with RS485 address
cable distance	Maximum 50m
Cable type	0.8mm diameter cable (AWG20)
General:
Body	ABS Plastic
body type	Standard
Colour	Black
Operating temperature	0ºC / +45ºC
Operating humidity	20-85%RH
Dimensions (HxWxD)	75x105x62mm
Weight	420g

Product name

Short description

Full description

Phase measurement range 120-300V AC / 1V sensitivity
Frequency measurement range 10-500 Hz / 0.1 Hz precision
Soil measurement range 0-20V AC / 1V sensitivity
Maximum cable distance 50m

Electrical:
Operating voltage range	4.5-5.5V DC
operating current	<2.6mA (5V DC)
Phase measurement range	120-300V AC
Phase measurement accuracy	1V
Frequency measuring range	100-500 Hz
Frequency measurement precision	0.1Hz
Soil measurement range	0-20V AC
Soil measurement accuracy	1V
Communication:
Protocol	MODBUS with RS485 address
cable distance	Maximum 50m
Cable type	0.8mm diameter cable (AWG20)
General:
Body	ABS Plastic
body type	Standard
Colour	Black
Operating temperature	0ºC / +45ºC
Operating humidity	20-85%RH
Dimensions (HxWxD)	75x105x62mm
Weight	420g

Product name

Short description

Full description

<ul><li>نطاق قياس المرحلة 120-300 فولت تيار متردد/حساسية 1 فولت</li><li>نطاق قياس التردد 10-500 هرتز / دقة 0.1 هرتز</li><li>نطاق قياس التربة 0-20 فولت تيار متردد/حساسية 1 فولت</li><li>الحد الأقصى لمسافة الكابل 50 م</li></ul><p><google-sheets-html-origin style=""></google-sheets-html-origin></p><table xmlns="http://www.w3.org/1999/xhtml" cellspacing="0" cellpadding="0" dir="ltr" border="1" data-sheets-root="1" style="table-layout: fixed; width: 0px; border-collapse: collapse; border: none;"><colgroup><col width="158"><col width="359"></colgroup><tbody><tr style="height: 21px;"><td rowspan="1" colspan="2" data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;الكهرباء:&quot;}" style="border: 1px solid rgb(0, 0, 0); overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">الكهرباء:</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;تعمل مجموعة الجهد&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">تعمل مجموعة الجهد</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;4.5-5.5 فولت تيار مستمر&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">4.5-5.5 فولت تيار مستمر</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;التشغيل الحالي&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">التشغيل الحالي</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;<2.6 مللي أمبير (5 فولت تيار مستمر)&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">&lt;2.6 مللي أمبير (5 فولت تيار مستمر)</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;نطاق قياس المرحلة&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">نطاق قياس المرحلة</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;120-300 فولت تيار متردد&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">120-300 فولت تيار متردد</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;دقة قياس المرحلة&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">دقة قياس المرحلة</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;1V&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">1V</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;نطاق قياس التردد&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">نطاق قياس التردد</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;100-500 هرتز&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">100-500 هرتز</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;دقة قياس التردد&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">دقة قياس التردد</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;0.1 هرتز&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">0.1 هرتز</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;نطاق قياس التربة&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">نطاق قياس التربة</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;0-20 فولت تيار متردد&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">0-20 فولت تيار متردد</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;دقة قياس التربة&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">دقة قياس التربة</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;1V&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">1V</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="2" data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;تواصل:&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">تواصل:</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;بروتوكول&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">بروتوكول</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;مودبوس مع عنوان RS485&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">مودبوس مع عنوان RS485</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;مسافة الكابل&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">مسافة الكابل</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;الحد الأقصى 50 م&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">الحد الأقصى 50 م</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;نوع الكابل&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">نوع الكابل</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;كابل بقطر 0.8 ملم (AWG20)&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">كابل بقطر 0.8 ملم (AWG20)</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="2" data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;عام:&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">عام:</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;جسم&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">جسم</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;بلاستيك ايه بي اس&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">بلاستيك ايه بي اس</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;نوع الجسم&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">نوع الجسم</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;معيار&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">معيار</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;لون&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">لون</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;أسود&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">أسود</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;درجة حرارة التشغيل&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">درجة حرارة التشغيل</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;0 درجة مئوية / +45 درجة مئوية&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">0 درجة مئوية / +45 درجة مئوية</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;رطوبة العملية&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">رطوبة العملية</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;20-85% رطوبة نسبية&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">20-85% رطوبة نسبية</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;الأبعاد (الارتفاع × العرض × العمق)&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">الأبعاد (الارتفاع × العرض × العمق)</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;75 × 105 × 62 ملم&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">75 × 105 × 62 ملم</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;ثقل&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">ثقل</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;420 جرام&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">420 جرام</td></tr></tbody></table>

نطاق قياس المرحلة 120-300 فولت تيار متردد/حساسية 1 فولت
نطاق قياس التردد 10-500 هرتز / دقة 0.1 هرتز
نطاق قياس التربة 0-20 فولت تيار متردد/حساسية 1 فولت
الحد الأقصى لمسافة الكابل 50 م

الكهرباء:
تعمل مجموعة الجهد	4.5-5.5 فولت تيار مستمر
التشغيل الحالي	<2.6 مللي أمبير (5 فولت تيار مستمر)
نطاق قياس المرحلة	120-300 فولت تيار متردد
دقة قياس المرحلة	1V
نطاق قياس التردد	100-500 هرتز
دقة قياس التردد	0.1 هرتز
نطاق قياس التربة	0-20 فولت تيار متردد
دقة قياس التربة	1V
تواصل:
بروتوكول	مودبوس مع عنوان RS485
مسافة الكابل	الحد الأقصى 50 م
نوع الكابل	كابل بقطر 0.8 ملم (AWG20)
عام:
جسم	بلاستيك ايه بي اس
نوع الجسم	معيار
لون	أسود
درجة حرارة التشغيل	0 درجة مئوية / +45 درجة مئوية
رطوبة العملية	20-85% رطوبة نسبية
الأبعاد (الارتفاع × العرض × العمق)	75 × 105 × 62 ملم
ثقل	420 جرام

Product name

Short description

Full description

<ul><li>Faz ölçüm aralığı 120-300V AC / 1V hassasiyet</li><li>Frekans ölçüm aralığı 10-500 Hz / 0.1 Hz hassasiyet</li><li>Toprak ölçüm aralığı 0-20V AC / 1V hassasiyet</li><li>Maksimum kablo mesafesi 50m</li></ul><p><google-sheets-html-origin style=""></google-sheets-html-origin></p><table xmlns="http://www.w3.org/1999/xhtml" cellspacing="0" cellpadding="0" dir="ltr" border="1" data-sheets-root="1" style="table-layout: fixed; width: 0px; border-collapse: collapse; border: none;"><colgroup><col width="149"><col width="335"></colgroup><tbody><tr style="height: 21px;"><td rowspan="1" colspan="2" data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Elektriksel:&quot;}" style="border: 1px solid rgb(0, 0, 0); overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Elektriksel:</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Çalışma voltaj aralığı&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Çalışma voltaj aralığı</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;4.5-5.5V DC&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">4.5-5.5V DC</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Çalışma akımı&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Çalışma akımı</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;<2.6mA (5V DC)&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">&lt;2.6mA (5V DC)</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Faz ölçüm aralığı&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Faz ölçüm aralığı</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;120-300V AC&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">120-300V AC</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Faz ölçüm hassasiyeti&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Faz ölçüm hassasiyeti</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;1V&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">1V</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Frekans ölçüm aralığı&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Frekans ölçüm aralığı</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;100-500 Hz&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">100-500 Hz</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Frekans ölçüm hassasiyeti&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Frekans ölçüm hassasiyeti</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;0.1 Hz&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">0.1 Hz</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Toprak ölçüm aralığı&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Toprak ölçüm aralığı</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;0-20V AC&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">0-20V AC</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Toprak ölçüm hassasiyeti&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Toprak ölçüm hassasiyeti</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;1V&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">1V</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="2" data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Haberleşme:&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Haberleşme:</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Protokol&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Protokol</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;RS485 adresli MODBUS&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">RS485 adresli MODBUS</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Kablo mesafesi&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Kablo mesafesi</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Maksimum 50m&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Maksimum 50m</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Kablo tipi&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Kablo tipi</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;0.8mm çaplı kablo (AWG20)&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">0.8mm çaplı kablo (AWG20)</td></tr><tr style="height: 21px;"><td rowspan="1" colspan="2" data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Genel:&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Genel:</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Gövde&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Gövde</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;ABS Plastik&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">ABS Plastik</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Gövde tipi&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Gövde tipi</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Standart&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Standart</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Renk&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Renk</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Siyah&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Siyah</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Çalışma sıcaklığı&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Çalışma sıcaklığı</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;0ºC / +45ºC&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">0ºC / +45ºC</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Çalışma nemi&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Çalışma nemi</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;%20-85 RH&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">%20-85 RH</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Boyutlar (HxWxD)&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Boyutlar (HxWxD)</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;75x105x62mm&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">75x105x62mm</td></tr><tr style="height: 21px;"><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;Ağırlık&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(240, 240, 240); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">Ağırlık</td><td data-sheets-value="{&quot;1&quot;:2,&quot;2&quot;:&quot;420g&quot;}" style="border-width: 1px; border-style: solid; border-color: rgb(204, 204, 204) rgb(0, 0, 0) rgb(0, 0, 0) rgb(204, 204, 204); border-image: initial; overflow: hidden; padding: 2px 3px; vertical-align: bottom; background-color: rgb(246, 246, 246); font-family: Roboto; font-size: 11pt; font-weight: normal; white-space: normal; overflow-wrap: break-word; color: rgb(60, 60, 59);">420g</td></tr></tbody></table>

Faz ölçüm aralığı 120-300V AC / 1V hassasiyet
Frekans ölçüm aralığı 10-500 Hz / 0.1 Hz hassasiyet
Toprak ölçüm aralığı 0-20V AC / 1V hassasiyet
Maksimum kablo mesafesi 50m

Elektriksel:
Çalışma voltaj aralığı	4.5-5.5V DC
Çalışma akımı	<2.6mA (5V DC)
Faz ölçüm aralığı	120-300V AC
Faz ölçüm hassasiyeti	1V
Frekans ölçüm aralığı	100-500 Hz
Frekans ölçüm hassasiyeti	0.1 Hz
Toprak ölçüm aralığı	0-20V AC
Toprak ölçüm hassasiyeti	1V
Haberleşme:
Protokol	RS485 adresli MODBUS
Kablo mesafesi	Maksimum 50m
Kablo tipi	0.8mm çaplı kablo (AWG20)
Genel:
Gövde	ABS Plastik
Gövde tipi	Standart
Renk	Siyah
Çalışma sıcaklığı	0ºC / +45ºC
Çalışma nemi	%20-85 RH
Boyutlar (HxWxD)	75x105x62mm
Ağırlık	420g
