Product features;

• Simple and additive control can work up to 10 stops

• Built-in automatic door relay

• Call lamp and buttons can be connected to the system with a cable.

• Simple and error-free assembly thanks to the built-in terminal board

• Cab serial communication output

• Adjustable parking stop and time to go to the park

• Password protected programming, company code protection against unauthorized use

• Counter bi-stable switch input for position information

• Adjustable maintenance time, warning on LCD when maintenance period is over

• Manual movement at slow speed using program buttons

• Display outputs with short circuit protection, adjustable for each station

• Selection of the floor with the fully automatic door of the elevators with only one fully automatic door.

• Converting display outputs to gray code or binary outputs

• Overload function

• Choice to move the car up to the limit switches or floor level in the revision

• Adjustable cabin lamp time, lock waiting time, floor waiting time, maximum high speed time and maximum low speed time

• SA relay contact outputs for direction arrows, out-of-service signal and busy signal; signal partner input for these outputs

• Optionally, the car is taken to the first stop when the first energy comes on.

• Electronic phases, phase sequence and PTC (Motor temperature) control, display of errors related to these controls on the LCD screen on

the board, these functions can be disabled by parameter selection, phase level sensitivity can be adjusted

• Warning function on the LCD screen on the card when the door is left open for a long time or when the stop return circuit cannot be

detected for a long time.
