Product features;
•VVVF Fast operation
•Operation up to 16 stops in parallel.
•Duplex operation
•Floor and cabin serial, parallel and ready-to-use installation options on one card
•En 81-1/2 +A3, 81-20, conforming to regulations
•Cabinet double door support on the same card
•Unintended cabin movement ( UCM ) control over the main board
•Internal leveling and door bridging relays
•Automatic detection of bridged door contacts
•Internal phase control
•Contactor control(KRC)
•Fire, earthquake functions and firefighter elevator functions
•Smart addressing with Heytech floor and cabin in-cassette cards
•Ability to adjust missing floors from the top and bottom in case of group work
•Well copy feature with motor encoder
•Odometer
•Maintenance timer
•Built-in music and announcement system
•Storing and monitoring error logs
•Easy panel assembly and ease of making ready-made installation panels with Heytech terminal cards
•With the support of automatic bringing to the floor (ups) in case of power cut
•Full load, overload, minimum load, boat functions
•Internal battery charging circuit and cabin fan relay on the revision board
•For the connection between the control panel and the cabin, a 28-wire flexible cable is sufficient.
