DescriptionReviews1 Description For use with internal data transfer systems. Used to transfer analog and digital signals at speeds up to 100 Mbit/s. Cable structure Conductor Solid Copper Ø 0,51 mm Insulation Poliolefin Ø 1,00 mm Sheath PVC RAL 7024 Gray Cable Diameter Ø 5,50 mm Cable Weight 35 Kg / Km Standard Length 305 / 500 /1000 m Code No 104 12014 2403 Technicial Specifications Conductor Resistance Max. 94Ω/Km Insulator Resistance min. 5GΩ/Km Impedance 100+ / -15Ω Effective Capacity Max. 56 nF / Km Operating voltage 250V Test Voltage 1200V Operating temperature -30°C ~ +70°C min. Bending Radius 5 x D Reviews Be the first to review this item There are no reviews yet Related products CAT 5 H-UTP 4x2x24 AWG Cable CAT 5e H-UTP 4x2x24 AWG Cable CAT 5e UTP 4x2x24 AWG Cable CAT 6 FTP 4x2x24 AWG Cable CAT 6 H-UTP 4x2x23 AWG Cable CAT 6 FTP PE 4x2x24 AWG Cable CAT 6 F UTP 4x2x23 AWG Cable CAT 6 F UTP 4x2x25 AWG Cable CAT 5 FTP 4x2x24 AWG Cable
