Description
- Product features :
- Agm batteries are dry batteries. And it is safe to use. Batteries convert electrical energy into chemical energy. The internal structure of
- these batteries is different from flooded batteries. It stores itself by charging method. They have lower electrical resistance. There is
- also lower acid stratification compared to flooded batteries. It has a high gas efficiency rate. And it has a lower acidity than others.
- Another feature of Agm batteries is their high power density. Its use is also more flexible. It is long lasting. It is used in many areas.
- It can be easily used especially in uninterruptible power supplies and telecommunication systems. These batteries do not leak acid. It is
- also safe because it has almost no gas emissions.
- Technological Features:
- This can be said for Agm batteries, especially VRLA batteries whose electrolyte is impregnated with separators. It is used in many places
- and is generally used in vehicles. Many things in the vehicle function thanks to the battery. And it is a very cheap method of providing
- uninterrupted energy. Agm batteries can be used especially in vehicles. These batteries are preferred because they are both easy to use and
- cheaper. They are placed inside uninterruptible power supplies. In some cases, when the efficiency of the UPS source increases and the
- battery grows, the battery is placed outside in a separate place and connected to the UPS devices. Battery life is generally 5 years. The
- important thing here is how much heat it is exposed to.
- Scope of application :
- Car
- Truck
- Tractor
- Caravan
- Ambulance
- Boat
- For Starting Purposes in Generators
Part Number: FZA 2.3-12 Length: 178 ± 2 mm (7.00 inches) Width: 35 ± 2 mm (1.38 inches) Container Height: 60 ± 2 mm (2.36 inches) Total Height (With terminal): 66 ± 2 mm (2.60 inches) Approx Weight: Approx 0.89kg (1.96lbs) Nominal Voltage 12V Nominal Capacity (20HR) 2.3 AH Terminal TypeStandard Terminal F1 Optional Terminal - Container MaterialStandard Option ABS Flame Retardant Option (FR) UL94VO Rated Capacity2 40 AH/0.115A (20hr, 1 BOV/cell. 25‘C / 77‘F) 2.23 AH/0.214A (10hr, 1.80V/cell, 25SC / 77‘F) 1.95AH/0 39A (5hr l 75V/cell, 25‘C / 77‘F) 1 79 AHU 59A (3hr. 1,75V/cell, 25‘C 177‘F) 1 44 AH/1 44A (Ihr. 1 60V/cell, 25‘C/77‘F) Max Discharge Current 34 5A(5s) Internal Resistance Approx 10 OmQ Discharge CharacteristicsOperating Temp. RangeDiecharge: -15 ~ 50‘C Charge: 0 - 40°C Storage: -15 - 40'C Nominal Operating Temp. Range 25+3°C (77+5°F ) Cycle Uoe Initial Charging Cunent less than 0 69A. Voltage 14.4V - 15.0V at 25‘C (77‘F) Temp Coefficient -30mV/*C Standby Use No limit on Initial Charging Cunent Voltage 13.5V - 13.8V at 25‘C (77‘F)Temp. Coefficient -20mWC Capacity affect by Temperature40‘C 103% 25"C 100% 0'C 86% Design Floating Life at 20°C 5 Years
