Description
- It complies with the transportation and transmission systems requirement that ensures accessibility for disabled people as required by the Ministry of National Education Private Education Institutions Regulation.
- In addition, the Ministry of Health, Municipality, etc. It also complies with the transportation and transmission systems requirements required for licensing procedures in institutions.
- Driving schools, kindergartens, private schools, study centers, etc. In all institutions affiliated with the Ministry of Education, cafes, clinics, etc.
- TECHNICIAL SPECIFICATIONS:
- Carrying capacity: 130 kg
- Main body material: Stainless steel
- Total weight: 52 kg (Main body 43 kg + seating unit 9 kg)
- Total width: 50 cm (armrest to armrest: 66 cm)
- Total depth: 92 cm (with pallet closed)
- Total height: 132cm
- Seating width: 38 cm (width between two armrests 50 cm)
- Seating depth. 46cm
- Back height: 66 cm (85 cm minimum including headboard)
- Height of seat from floor: 51 cm
- Rear wheel diameter: 25 cm (infill)
- Front wheel diameter: 10 cm (drunk wheel, filler)
- Pallet length: 80 cm
- Pallet width: 2.7 cm
- Battery: 12 Volt 12 Ampere (2 pieces) (maintenance-free dry type)
- Driving Motor: 120 Watt 24v
- Actuator Motor: 24 V DC (maximum capacity 6000 n/push-4000n/pull, speed 4mm/s)
- It is suitable for flat/landing (non-revolving) stairs. It is also possible to use it on inclined surfaces.
- Thanks to its pallet length and angle adjustable structure, it provides a safer ride by leaning on 3 steps.
- 4-way handcuffs have locks
- Can be divided into two parts: seat and main chassis
- Armrest height and depth adjustable
- Attendant arms height adjustable
- It has a slim and elegant design.
- It has fireproof flooring in accordance with TSE guidelines
- Pallet angle can be adjusted via the control panel.
- This enables the user to travel in maximum comfort.
- The battery indicator has a digital display.
- There is an emergency lock button on the unit.
- There are Driving and Angle Adjustment buttons and on-off buttons on the control panel.
